Hitech PWS6710T-N, PWS6710T-P
PWS6710
Hitech
12 tháng
LH: 0938070068
Display
Size diagonal | 7" diagonal |
Resolution | 800x480 pixels |
Backlight | LED Backlight |
Backlight life time | min 20,000 hours |
Backlight brightness | 350 cd/m2 |
Backlight dimming | None |
Display type | Color TFT LCD |
Communication serial
Number of serial ports | 2 Port 9pin DSUB/1 Port 25pin DSUB |
Serial port 1 | RS232/RS485 |
Serial port 2 | RS 232/RS422/Rs485 |
Serial port 3 | RS422/485 |
Expansion interface
SD card | CF |
USB | 2 USB Host, 1 USB Device |
Mechanical
Mechanical size | 231.0 x 176.0 x 46.8 mm |
Number of touches | 1million finger touch operations |
Touch type | Resistive |
Cut-out size | 220.8 x 165.8 mm |
Weight | 1.64 kg |
Housing material | Plastic, Gray |
Power
Input voltage | 24V DC ± 15% |
Power consumption (max) | 24VDC, 24W |
Input fuse | Internal DC fuse |
