Weintek MT8104XH

Display

10.4" TFT LCD

Brightness (cd/m2)

400 cd/m2

Contrast Ratio

400:1

Color

65536

Resolution (W x H)

800 x 600

Back Light

LED

Back Light Life Time

30,000 hr

Touch Panel Type

4 wires resistive type

Storage

256MB D.O.M

RAM (RAM)

256MB DDR 400MHz

SD Card Slot

Yes

USB Host

USB 2.0 Full Speed Host port x 2

USB Client

N/A

Ethernet Port

10/100 Base-T

COM Port

COM1(RS-232/RS-485 2W/4W), COM2(RS-232), COM3(RS-232/RS-485 2W)

Video Input Port

NTSC/PAL RCA x 2 (Optional) V2 only

Audio

Audio Line Out x 1 / Mic In x 1

Input Power

24 ±10% VDC

Power Consumption

1.25A@24VDC

Panel Cutout (W x H)

259x201mm

Weight (KG)

Approx 1.6kg

CE

Compilies with EN 55022:2006,Class A , EN 61000-3-2:2006, EN 61000-3-3:1995+A1:2001+A2:2005 standardss

UL

E248297

Voltage Resistance

500 VAC (1 min)

Isolation Resistance

Exceed 50MΩ at 500 VDC

Vibration Endurance

10 to 25 Hz (X,Y,Z direction 2G 30minutes)

Protection Structure

IP65 front panel (O ring seal)

Storage Temperature

-20°~60°C (-4°~140°F)

Operating Temperature

0°~50°C (32°~122°F)

Operation Humidity

10-90% RH (non-condense)
