Display |
Display |
10" TFT Widescreen |
Brightness (cd/m2) |
300 cd/m2 |
Contrast Ratio |
500:1 |
Color |
65536 |
Resolution (W x H) |
800 x 480 |
Back Light |
LED |
Back Light Life Time |
30,000 hr |
|
Processor |
32bit RISC CPU 400 MHz |
Enclosure |
Plastic |
Touch Panel |
Touch Panel Type |
4 wires resistive type |
|
Memory |
Storage |
128 MB Flash |
RAM (RAM) |
64 MB |
|
I/O ports |
SD Card Slot |
Yes |
USB Host |
USB 1.1 x 1 |
USB Client |
USB 2.0 x 1 |
Ethernet Port |
10/100 Base-T |
COM Port |
COM1(RS-232/RS-485 2W/4W), COM2(RS-232), COM3(RS-232/RS-485 2W) |
Audio |
YES |
|
Power |
Input Power |
24 ±20% VDC |
Power Consumption |
300mA@24VDC |
|
RTC |
Built-in |
Specification |
Panel Cutout (W x H) |
259x201mm |
Weight (KG) |
Approx 1.4kg |
|
Certification |
CE |
Compilies with EN 55022:2006,Class A , EN 61000-3-2:2006, EN 61000-3-3:1995+A1:2001+A2:2005 standards |
UL |
E248297 |
|
Operation |
Voltage Resistance |
500 VAC (1 min) |
Isolation Resistance |
Exceed 50MΩ at 500 VDC |
Vibration Endurance |
10 to 25 Hz (X,Y,Z direction 2G 30minutes) |
Protection Structure |
IP65 front panel (O ring seal) |
Storage Temperature |
-20°~60°C (-4°~140°F) |
Operating Temperature |
0°~50°C (32°~122°F) |
Operation Humidity |
10-90% RH (non-condense) |
|
