WEINTEK MT8070iE

Liên hệ: 0938.07.00.68
Email: dung0938070068@gmail.com
Skype: dung0938070068

Display

Display 7” TFT

Resolution 800 x 480

Brightness (cd/m2) 350

Contrast Ratio 500:1

Backlight Type LED

Backlight Life Time >30,000 hrs.

Colors 16M

Touch Panel Type 4-wire Resistive Type

Accuracy Active Area Length(X)±2%, Width(Y)±2%

Memory Flash 128 MB

RAM 128 MB

Processor 32 bits RISC Cortex-A8 600MHz

I/O Port

SD Card Slot N/A

USB Host USB 2.0 x 1

USB Client N/A

Ethernet 10/100 Base-T x 1

COM Port

 COM1: RS-232/RS-485 2W/4W

COM3: RS-485 2W

RS-485 Dual Isolation Yes

CAN Bus N/A

HDMI N/A

Audio Output N/A

Video Input N/A

RTC Built-in

Power

Input Power 24±20% VDC

Power Isolation N/A

Power Consumption 350mA@24VDC

Voltage Resistance 500VAC (1 min.)

Isolation Resistance Exceed 50M at 500VDC

Vibration Endurance 10 to 25Hz (X, Y, Z direction 2G 30 minutes)

Specification

PCB Coating Yes

Enclosure Plastic

Dimensions WxHxD 200.3 x 146.3 x 34 mm

Panel Cutout 192 x 138 mm

Weight Approx. 0.6 kg

Mount Panel mount

Environment

Protection Structure UL Type 4X (indoor use only) / NEMA4 / IP65 Compliant

Front Panel

Storage Temperature -20° ~ 60°C (-4° ~ 140°F)

Operating Temperature 0° ~ 50°C (32° ~ 122°F)

Relative Humidity 10% ~ 90% (non-condensing)

Certificate CE CE marked

UL cULus Listed

Software EasyBuilder Pro V3.00.01 or later versions
