Module nhiệt FATEK FBs-6RTD

Module Nhiệt Độ Fatek FBs-6RTD

Expansion Type: Right Side
Total Channels: 6 CH
Resolution: 0.1℃ or 1℃
I/O Points Occupied: 1 RI(Input Register) and 8 DO - B1 PLC support up to 64 IR
Conversion Time: 1 or 2 Seconds
Accuracy: ±1 %
Sensor Type: Pt-100, Pt-1000 (JIS or DIN )
Software Filter: Moving Average
Average Samples: 1, 2, 4, 8, 16 Samples
Measurement Range: Pt-100: -200 ~ 850℃, Pt-1000: -200 ~ 600℃
Isolation: Transformer (Power) and Photo-couple (Signal)
Indicator(s): 5V PWR LED
Supply Power: 24V-15%/+20%, 2VA
Internal Power Consumption: 5V, 35mA
