| Output voltage |
Output current |
Screw terminal Model | Connector terminal Model *3 | ||
|---|---|---|---|---|---|
| With Bus Line Connectors *1 |
Without Bus Line Connectors *2 |
With Bus Line Connectors *1 |
Without Bus Line Connectors *2 |
||
| 5 V | 5 A | --- | S8TS-02505 | --- | S8TS-02505F |
| 12 V | 2.5 A | S8TS-03012-E1 | S8TS-03012 | S8TS-03012F-E1 | S8TS-03012F |
| 24 V | 2.5 A | S8TS-06024-E1 | S8TS-06024 | S8TS-06024F-E1 | S8TS-06024F |
Bus Line Connector
| Specifications | Number of Connectors | Model number |
|---|---|---|
| Connector with DC line connected (For parallel operation) |
1 Connector | S8T-BUS01 |
| 10 Connectors *4 | S8T-BUS11 | |
| Connector with DC line not connected (Not for parallel operation) |
1 Connector | S8T-BUS02 |
| 10 Connectors *5 | S8T-BUS12 |
*1. One S8T-BUS01 Connector and one S8T-BUS02 Connector are included as accessories.
*2. Bus Line Connectors are ordered separately. When connecting Power Supplies with Bus Line Connectors, order the
Bus Line Connectors separately.
*3. Attached connectors: 2ESDPLM-05P (for output terminal) and 3ESDPLM-03P (for input terminal) made by DINKLE
ENTERPRISE.
*4. One package contains 10 S8T-BUS01 Connectors.
*5. One package contains 10 S8T-BUS02 Connectors.
*2. Bus Line Connectors are ordered separately. When connecting Power Supplies with Bus Line Connectors, order the
Bus Line Connectors separately.
*3. Attached connectors: 2ESDPLM-05P (for output terminal) and 3ESDPLM-03P (for input terminal) made by DINKLE
ENTERPRISE.
*4. One package contains 10 S8T-BUS01 Connectors.
*5. One package contains 10 S8T-BUS02 Connectors.
