Proface GLC2300-LG41-24V, (PFXGL2300LD)
GLC2300-LG41-24V
Proface
2t
Liên hệ: 0938.070.068 Mr Dũng
Mail: dung0938070068@gmail.com
Skype: dung0938070068
Liên hệ: 0938.070.068
Liên hệ: 0938.070.068 Mr Dũng
Mail: dung0938070068@gmail.com
Skype: dung0938070068
| Model (Global Code) |
GLC2300-LG41-24V (PFXGL2300LD) |
||
|---|---|---|---|
| Type | Monochrome LCD | ||
| Display Colors | Black and White (2 Shades)/ Black and White (8 Shades) (software control)*1 |
||
| Backlight | CCFL (Service life: more than 50,000 at 24 hr. operation) | ||
| Resolution | 320 x 240 pixcels | ||
| Effective Display Area (mm) | 115.2(W) × 86.4(H) | ||
| Brightness Control | 4 levels of adjustment available via touch panel | ||
| Contrast Control | 8 levels of adjustment available via touch panel | ||
| Language Character Sets | ASCII: (Code page 850) Alphanumeric (incl. European characters) Chinese: (GB2312-80 codes) simplified Chinese fonts Japanese: ANK 158, Kanji: 6962 (JIS Standards 1 & 2) Korean: (KSC5601 - 1992 codes) Hangul fonts Taiwanese: (Big 5 codes) traditional Chinese fonts |
||
| Text | 8 × 8 dots | 40 char. × 30 rows | |
| 8 ×16 dots | 40 char. × 15 rows | ||
| 16 × 16 dots | 20 char. × 15 rows | ||
| 32 × 32 dots | 10 char. × 7 rows | ||
| Character Sizes*2 | 8 × 8 dots, 8 × 16 dots, 16 × 16 dots, 32 × 32 dots | ||
| Font Sizes | Width can be expanded 1 to 8 times Height can be expanded 1/2*3, 1 to 8 times |
||
| Application Memory | FLASH EPROM 2MB | ||
| Data Backup Memory | 256 KB - uses lithium battery*4 | ||
| Control Memory*5 |
Program Area: FLASH EPROM 128KB |
||
| Touch Panel Resolution | 16 × 12 keys/ screen - 1 or 2 point touch | ||
| External Interfaces |
Serial Interface | Asynchronous Transmission: RS-232C/ RS-422, Data Length: 7 or 8 bits, Stop bit: 1 or 2 bits, Parity: Odd or Even, Data Transmission Speed: 2400bps to 115.2Kbps, 187.5Kbps*7 |
|
| Expansion Serial Interface | Asynchronous Transmission: RS232C/ RS422 Data Length: 7 or 8 bits Stop Bit: 1 or 2 bits Parity: None, Odd or Even Data Transmission Speed: 2400 to 115.2kbps |
||
| Network Interface | IEEE802.3, 10BASE-T | ||
| CF Card Interface | 1 slot | ||
| FLEX NETWORK |
Communication Configuration |
1:N | |
| Connection Method |
Multi-Drop Connection | ||
| Max. Distance | 200m/channel at 6Mbps, 100m/channel at 12Mbps |
||
| Communication Method |
Cyclic Time Division, half-duplex | ||
| Communication Speed |
6Mbps/ 12Mbps | ||
| Communication I/F |
Differential, pulse-transformer isolation | ||
| Error Check | Format, bit, CRC-12 verification | ||
| Max. Number of Nodes |
63 (1008 I/O points) | ||
| Tool Connector | Asynchronous TTL level nonprocedure command I/F Used for transferring data between the GLC application software and the GLC. Used for data transfer with the 2-Port feature. Used for a variety of devices, including a bar-code reader. |
||
- In order to set the monochrome (eight levels of gray) mode, GP-PRO/PBIII for Windows Ver. 6.2 or later is required. Depending on the color used, selecting MONOCHROME 8 HUES may cause the GP unit's screen to flicker and make it difficult to distinguish colors. Confirm that all colors display as expected prior to using this mode.
- The display font will differ depending on which (language) character, or which size you select.
- Only available when using "1/2 Byte Character" settings via software. (Only Japanese, Chinese, Taiwanese and Korean characters.)
- A Lithium battery's lifetime is:
10 years when the battery's ambient temperature is under 40℃
4.1 years when the battery's ambient temperature is under 50℃
1.5 years when the battery's ambient temperature is under 60℃
When used for backup:
Approximately 60 days, with a fully charged battery
Approximately 6 days, with a half-charged battery - The 128-KB program area is allotted in SRAM for online editing use.
- 64KB of Variable data area are supported by Revision 2 or later in GLC model. Prior to Revision 1 is 32KB. The revision code can be easily found using the GLC unit's rear face identification label or revision sticker. In the area titled "REV",the code is indicated by asterisks(*) or marked with a marker pen. Please go to the GLC User Manual for more details.
- SIEMENS SIMATIC S7-200/300/400 Series (MPI port only). Please contact your Pro-face sales representative for supported models and other details.
