MODEL NO.
|
Current Control
|
Max Load Current
|
Rated Operational
Voltage
|
Non-rep. peak
Voltage
|
Insulation Voltage
Input-Output
|
Insulation Voltage
Output-Case
|
CATALOG DOWNLOAD
|
KC4010AX
|
4~20mA
( DC3.8~10V )
|
10A
|
48~480VAC
|
1200V peak
|
4000Vrms
|
2500Vrms
|
|
KC4015AX
|
4~20mA
( DC3.8~10V )
|
15A
|
48~480VAC
|
1200V peak
|
4000Vrms
|
2500Vrms
|
KC4025AX
|
4~20mA
( DC3.8~10V )
|
25A
|
48~480VAC
|
1200V peak
|
4000Vrms
|
2500Vrms
|
KC4040AX
|
4~20mA
( DC3.8~10V )
|
40A
|
48~480VAC
|
1200V peak
|
4000Vrms
|
2500Vrms
|
KC4050AX
|
4~20mA
( DC3.8~10V )
|
50A
|
48~480VAC
|
1200V peak
|
4000Vrms
|
2500Vrms
|
KC4075AX
|
4~20mA
( DC3.8~10V )
|
75A
|
48~480VAC
|
1200V peak
|
4000Vrms
|
2500Vrms
|
KC4090AX
|
4~20mA
( DC3.8~10V )
|
90A
|
48~480VAC
|
1200V peak
|
4000Vrms
|
2500Vrms
|
|
|
|
MODEL NO.
|
Operational
Frequency Range
|
Power Factor
|
Operating
Temperature
|
Storage
Temperature
|
Junction Temperature
|
Weight (g)
|
CE-marking
|
|
|
|
0° to +70c °
|
-20c° to +100c°
|
125c °
|
Approx.
100g
|
Yes
|
KC4015AX
|
40 to 65 Hz
|
>0.90
|
0° to +70c °
|
-20c° to +100c°
|
125c °
|
Approx.
100g
|
Yes
|
KC4025AX
|
40 to 65 Hz
|
>0.90
|
0° to +70c °
|
-20c° to +100c°
|
125c °
|
Approx.
100g
|
Yes
|
KC4040AX
|
40 to 65 Hz
|
>0.90
|
0° to +70c °
|
-20c° to +100c°
|
125c °
|
Approx.
100g
|
Yes
|
KC4050AX
|
40 to 65 Hz
|
>0.90
|
0° to +70c °
|
-20c° to +100c°
|
125c °
|
Approx.
100g
|
Yes
|
KC4075AX
|
40 to 65 Hz
|
>0.90
|
0° to +70c °
|
-20c° to +100c°
|
125c °
|
Approx.
100g
|
Yes
|
KC4090AX
|
40 to 65 Hz
|
>0.90
|
0° to +70c °
|
-20c° to +100c°
|
125c °
|
Approx.
100g
|
Yes
|
|
|
Output Specifications |
|
Mini Operational
Current
|
Rep. overload
Current t=1s
|
Non-rep. Surge
Current t=10ms
|
Off-state leakage
Current
|
I2t for fusing
t=1 - 10 ms
|
Critical dl/dt
@50hz
|
Critical dV/dt
off-state min.
|
10A
|
150mA
|
25A p
|
120A p
|
<4mA
|
60A 2 s
|
100A/ μ
|
1000V/μ
|
15A
|
150mA
|
25A p
|
168A p
|
<4mA
|
180A 2 s
|
100A/ μ
|
1000V/μ
|
25A
|
150mA
|
25A p
|
300A p
|
<4mA
|
400A 2 s
|
100A/ μ
|
1000V/μ
|
40A
|
150mA
|
25A p
|
420A p
|
<4mA
|
1250A 2 s
|
100A/ μ
|
1000V/μ
|
50A
|
150mA
|
25A p
|
520A p
|
<4mA
|
1300A 2 s
|
100A/μ
|
1000V/μ
|
75A
|
150mA
|
25A p
|
750A p
|
<4mA
|
1800A 2 s
|
100A/ μ
|
1000V/μ
|
90A
|
150mA
|
25A p
|
1400A p
|
<4mA
|
7200A 2 s
|
100A/ μ
|
1000V/μ
|
|
|
Input Specifications |
|
Control current
Range
|
Pick up Current
|
Drop out Current
|
Response time
(Input - Output )
|
Off-state leakage
Current
|
Dynamic
Impedance
|
Allowable input
Current (max.)
|
Reverse Polarity
Protected
|
4~20mA
|
4mA
|
3.5mA
|
10ms
|
>10VDC @20mA
|
150
|
50mA
|
Yes
|
|
