MODEL
NO.
|
CONTROL
IMPEDANCE
|
MUST TURN
OFF VOLTAGE
|
INPUT
IMPEDANCE
|
MAX LOAD
CURRENT
|
LOAD VOLTAGE
RANGE
|
MIN BLOCKING
VOLTAGE
|
MAX OFF-STATE
LEAKAGE
|
FREQUENCY
RANGE
|
MAX 1-CYCLE
PEAK SURGE
|
CATALOG DOWNLOAD
|
K3P40R25DA
|
12TO32VDC
|
MAX9.5VDC
|
1.5Kohm
|
25A
|
48~480VAC
|
1200VAC
|
LESS 10mA
|
47~63Hz
|
315A
|
|
K3P40R40DA
|
12TO32VDC
|
MAX9.5VDC
|
1.5Kohm
|
40A
|
48~480VAC
|
1200VAC
|
LESS 10 mA
|
47~63Hz
|
450A
|
K3P40R50DA
|
12TO32VDC
|
MAX9.5VDC
|
1.5Kohm
|
50A
|
48~480VAC
|
1200VAC
|
LESS 10 mA
|
47~63Hz
|
560A
|
K3P40R75DA
|
12TO32VDC
|
MAX9.5VDC
|
1.5Kohm
|
75A
|
48~480VAC
|
1200VAC
|
LESS 10mA
|
47~63Hz
|
750A
|
K3P40R90DA
|
12TO32VDC
|
MAX9.5VDC
|
1.5Kohm
|
90A
|
48~480VAC
|
1200VAC
|
LESS 10mA
|
47~63Hz
|
900A
|
K3P40R100DA
|
12TO32VDC
|
MAX9.5VDC
|
1.5Kohm
|
100A
|
48~480VAC
|
1200VAC
|
LESS 10 mA
|
47~63Hz
|
1000A
|
|
|
MODEL
NO.
|
MAX OFF
STATE dv/dt
|
MAX ON-STATE
VOLTAGE DROP
|
ISOLATE
IMPEDENCE
|
DIELECTRIC STRENGTH
INPUT-OUTPUT
|
DIELECTRIC STRENGTH
INPUT,OUTPUT-CASE
|
TURN ON
TIME
|
TURN OFF
TIME
|
CAPACITANCE
IN-OUT
|
WEIGHT (g)
|
K3P40R25DA
|
500 SEC
|
1.6Vrms
|
ohm
|
2500Vrms
|
2500Vrms
|
LESS1/2cycle
|
LESS1/2cycle
|
LESS 473pf
|
600 g
|
K3P40R40DA
|
500 SEC
|
1.6Vrms
|
ohm
|
2500Vrms
|
2500Vrms
|
LESS1/2cycle
|
LESS1/2cycle
|
LESS 473pf
|
600 g
|
K3P40R50DA
|
500 SEC
|
1.6Vrms
|
ohm
|
2500Vrms
|
2500Vrms
|
LESS1/2cycle
|
LESS1/2cycle
|
LESS 473pf
|
600 g
|
K3P40R75DA
|
500 SEC
|
1.6Vrms
|
ohm
|
2500Vrms
|
2500Vrms
|
LESS1/2cycle
|
LESS1/2cycle
|
LESS 473pf
|
600 g
|
K3P40R90DA
|
500 SEC
|
1.6Vrms
|
ohm
|
2500Vrms
|
2500Vrms
|
LESS1/2cycle
|
LESS1/2cycle
|
LESS 473pf
|
600 g
|
K3P40R100DA
|
500 SEC
|
1.6Vrms
|
ohm
|
2500Vrms
|
2500Vrms
|
LESS1/2cycle
|
LESS1/2cycle
|
LESS 473pf
|
600 g
|
|
---------------------------------------------------------------------
