Thay thế Proface GP37W2-BG41-24V,GP377-SC11-24V,GP377-LG11-24V, GP377-LG41-24V, GP377-SC41-24V bởi PFXGM4301TAD, PFXGP4301TADW, PFXGP4301TAD

Model in use

Comments

GP37W2-BG41-24V

GP37W Series

5.7" Blue mode Monochrome LCD

Recommended Substitutes

Comments

Details

PFXGP4301TAD

GP4000M Series
modular type(22mm circular hole)
panel cut-out size difference

PFXGP4301TADW

GP4000 Series
panel cut-out size different
attachment available
(model:CA4-ATM5-01)
TFT color LCD
(Available Monochrome mode)

GP-377S / GP-377L

GP-4301TM

The panel cutout of GP-4301TM(link is external)is a φ22-mm circular hole.
If prefer to the standard type,
please refer to replacement guidebook GP-4301TW(link is external).

Model No.

GP-377S: GP377-SC11-24V/GP377-SC41-24V
GP-377L: GP377-LG11-24V/GP377-LG41-24V

PFXGM4301TAD

Specification Comparison

GP-377S: STN Color LCD
GP-377L: Monochrome LCD

TFT Color LCD

Display Colors

GP-377S: 64 colors(with blink)
GP-377L: Monochrome(with blink)

65,536 colors
(without blink) *1

Display Resolution

QVGA（320×240 pixels）

Panel Cutout Dimensions (mm)

W156×H123.5mm

NEW!
φ22mm　*1

External Dimensions (mm)

W171×H138×D57mm

NEW!
W163×H129.4×D56.5mm
(The rear module is included)　*1

Touch Panel Type

Resistive film (Matrix)

NEW!
Resistive film (Analog)　*1

Memory (Application)

1Mbyte

UP!
8M byte

Memory (SRAM)

96Kbyte

128Kbyte

Backup Battery

Rechargeable Lithium battery

- *1

Serial I/F (COM1)

D-Sub25 pin（socket）
RS-232C/422

NEW!
D-Sub9 pin（plug）
RS-232C/422/485　*1

Ethernet I/F

-

NEW!
10BASE-T/100BASE-TX

Tool Connector

✔

- *1

USB Type A

-

NEW!
✔

USB Type mini B

-

Expansion Unit I/F
(For Communication Unit)

✔

-

GP-37W2

GP-4301TW

Model No.

GP37W2-BG41-24V

PFXGP4301TADW

Display Type

Monochrome blue mode LCD

UP!
TFT Color LCD

Display Colors

Blue mode, no levels

65,536 colors(without blink)/
16,384 colors(with blink)*1

Display Resolution

QVGA(320×240 pixels)

Panel Cutout Dimensions (mm)

W191.5×H141.5mm

W156×H123.5mm*1

External Dimensions (mm)

W207×H157×D58mm

W169.5×H137×D59.5mm

Touch Panel Type

Resistive film (Matrix)

NEW!
Resistive film (Analog)*1

Memory (Application)

1MB

UP!
8MB

Memory (SRAM)

96KB

UP!
128KB

Backup Battery

Secondary Battery
(Rechargeable Lithium battery)

Serial I/F (COM1)

D-Sub25 pin (socket)
RS-232C/422

D-Sub9 pin (plug)
RS-232C*1

Serial I/F (COM2)

-

D-Sub9 pin (plug)
RS-422/485*1

Ethernet I/F

-

NEW!
10BASE-T/100BASE-TX

Tool Connector

✔

-

USB Type A

-

NEW!
✔*1

USB Type mini B

-
