Proface PS3710A-T42-24V

(1 đánh giá)

Mã sản phẩm : PS3710A-T42-24V

Xuất xứ : Proface

Bảo hành : 12t

Liên hệ: 0938.070.068 Mr Dũng Mail: dung0938070068@gmail.com Skype: dung0938070068

LH: 0938070068

THÔNG TIN SẢN PHẨM

Liên hệ: 0938.070.068 Mr Dũng
Mail: dung0938070068@gmail.com
Skype: dung0938070068

Display Type		TFT Color LCD
Display Size		15"
Resolution		1,024 x 768 pixels (XGA)
Dot pitch		W0.297 x H0.297 mm [W0.01 x H0.01 in.]
Effective Display Area		W304.1 x H228.1 mm [W11.97 x H8.98 in.]
Display Colors		262,144 Colors
Backlight		When PS-A Revision 5 and later: LED (When replacement is required,contact your local GP distributor) When PS-A Revision 5 and earlier: CCFL (Replaceable)
Brightness Control		4 Levels (Adjusted with the software)
Contrast Control		Not applicable
Backlight Service Life		50,000 hrs. or more (continuous operation at 25℃ before backlight brightness decreases to 50% or backlight starts to blink)
Supported OS		Windows® 2000/Windows® XP/Windows® XP Embedded
CPU		Intel® Pentium® M 1.6 GHz
L2 Cache Memory		1 MB (Built in the CPU)
Main Memory		DDR SDRAM (PC2700), 256 MB/512 MB/1 GB/2 GB (SO-DIMM socket x 2 slots)
Chipset		Intel® 855GME + ICH4
Graphics Accelerator		Built in Intel® 855GME
Video Memory		64 MB or less (When using Windows®) UMA Type
Graphics		XGA (1,024 x 768 pixels)
BIOS		Phoenix® First BIOS Embedded Pro
Clock Accuracy		±180 sec. /month (deviation at room temperature and power is OFF)
Touch Panel Type		Resistive Film (analog)
Touch Panel Resolution		1,024 X 1,024
Touch Panel Service Life		1,000,000 times or more, Sweeping 100,000 times or more
Touch Panel Interface		Internal Serial or Internal USB
Interface	IDE	2.5" HDD or SSD x 1 (Primary Master), CF Card Slot (Type II) x 1 (Primary Slave), DVD-ROM Drive (Secondary Master)
	Serial (COM1)	RS-232C (RI/+5 V switch possible), Connector: D-Sub9 (plug)
	Serial (COM2)	RS-232C (RI/+5 V switch possible), Connector: D-Sub9 (plug)
	Serial (COM3)	RS-232C (RS-232C/422/485 switch possible), Connector: D-Sub9 (plug)
	Serial (COM4)	RS-232C (Cannot use with touch panel), Connector: D-Sub9 (plug)
	Ethernet (LAN1)	IEEE802.3i/IEEE802.3u, 10BASE-T/100BASE-TX, Connector: Modular jack (RJ-45) x 1
	Ethernet (LAN2)	IEEE802.3i/IEEE802.3u/IEEE802.3ab, 10BASE-T/100BASE-TX/1000BASE-T, Connector: Modular jack (RJ-45) x 1
	USB (TYPE-A)	Conforms to USB2.0 (TYPE-A) x 5, Power Supply Voltage: DC 5 V ±5 %, Output Current: 500 mA or less, Communication Distance: 5 m or less
	Keyboard	PS/2 Connector: mini DIN 6 pin
	RAS	Input: 4 points, Output: 4 points , Rated voltage: DC 24 V , Maximum rated current: 100 mA , External reset input: 1 point, Input voltage: DC 12 to 24 V, Connector: D-Sub25 (plug) x 1
	Sound	Speaker output, line input, and mic input, Connector: mini-pin jack x 3
	PCMCIA	PC Card Slot, Card Bus supported connector (*except for Zoomed Video, Sound features): Type II X 1, Type III X 2
	Floppy Disk	2-mode 3.5" floppy disk drive x 1
	CD/DVD-ROM Drive	DVD-ROM Drive (option)

Depending on the operating temperature and age of unit, the clock can deviate ±300 sec./month. For systems where this level of deviation is a problem, the user should monitor and make adjustments when required.
Can be switched between Primary Master and Slave via the settings.
Wake On LAN supported.
The unit with Rev.1 does not have a floppy disk interface. Click to know how to confirm the revisions.
