Proface LT-4201M DIO Model, (PFXLM4201TADDC)
PFXLM4201TADDC
Proface
12 tháng
Liên hệ: 0938.070.068
Rated Input Voltage | 24 Vdc |
---|---|
Input Voltage Limits | 20 to 28.8 Vd |
Acceptable Voltage Drop | 10 ms or less at 20.4 Vdc |
Power Consumption | 9 W or less |
In-Rush Current | 30 A or less at 28.8 Vdc |
Voltage Endurance between power terminal and frame ground (FG) | 500 Vdc for 1 minute |
Insulation Resistance between power terminal and FG | 10 MΩ or higher at 500 Vdc |
Type | TFT Color LCD | ||
---|---|---|---|
Resolution (pixels) | 320 x 240 (QVGA) | ||
Active display area (W x H) | 70.56 x 52.92 mm (2.78 x 2.08 in.) | ||
Display Colors | 65,536 colors | ||
Backlight | White LED | ||
Non-exchangeable | |||
LED ON / OFF control, adjustable screen saver activation time | |||
Brightness adjustment | 16 levels of adjustment available via touch panel in the configuration menu | ||
Language Fonts *1 | Japanese, ASCII, Chinese (Simplified), Chinese (Traditional), Korean, Cyrillic, Thai | ||
Character sizes | 8 x 8, 8 x 16, 16 x 16 and 32 x 32 pixel fonts | ||
Font sizes | Width can be expanded 1 to 8 times. Height can be expanded 1/2 and 1 to 8 times. | ||
8 x 8 pixels | 40 characters per row x 30 rows | ||
8 x 16 pixels | 40 characters per row x 15 rows | ||
16 x 16 pixels | 20 characters per row x 15 rows | ||
32 x 32 pixels | 10 characters per row x 7 rows | ||
Memory | Application memory *2 | FLASH EPROM 16 MB (includes screen editing program and extended logic program) |
|
Logic program area | FLASH EPROM 132 KB *3 (equivalent to 15,000 steps) | ||
Font area | FLASH EPROM 8 MB (when limit exceeded, uses application memory) | ||
Data backup | nvSRAM 128 KB (rechargeable lithium battery for data backup) | ||
Variable area | nvSRAM 64 KB (rechargeable lithium battery for data backup) | ||
Touch Panel | Type | Resistive Film (analog) | |
Lifetime | 1 million touches or more | ||
Interface | Serial (COM1) | RS-232C/RS485 x 1 RS-232C (Connector type: RJ45, Isolation: None, Maximum baud rate: 115,200 bps, Cable Type: Shielded, Cable Maximum length: 15 m (49 ft), 5 Vdc power supply for RS-232C: None) RS-485 (Connector type: RJ45, Isolation: None, Maximum baud rate: 115,200 bps, Cable Type: Shielded, Cable Maximum length: 200 m (656 ft), Polarization: Setting is required via software when connecting Multiple LTs. Refer to the "GP-Pro EX Device/ PLC Manual" for the setting. 5 Vdc power supply for RS-485: None) *4 |
|
Ethernet | IEEE802.3 compliant Ethernet x 1 (Connector type: RJ45, Driver: 10 M half duplex (auto negotiation)/ 100 M full duplex (auto negotiation), Cable type: Shielded, Automatic cross-over detection: Yes) |
||
USB (Type A) | USB 2.0 (Type A) x 1 (Power Supply Voltage: 5Vdc +/-5%, Maximum Current Supplied: 500mA, Maximum Transmission Distance: 5m (16.4 ft.)) |
||
USB (Mini-B) | USB 2.0 (Mini-B) x 1 | ||
Control | DIO(Source Type) | 20 Points Standard Input (including 2 Points for Fast Input) 10 Points Standard Output, 2 Points for Fast Output |
