Proface GP2500-SC41-24V, (PFXGP2500SD)

Proface GP2500-SC41-24V, (PFXGP2500SD)

(1 đánh giá)

GP2500-SC41-24V

Proface

12t

Liên hệ: 0938.070.068 Mr Dũng Mail: dung0938070068@gmail.com Skype: dung0938070068

LH: 0938070068

Liên hệ: 0938.070.068 Mr Dũng Mail: dung0938070068@gmail.com Skype: dung0938070068

Model (Global Code) GP2500-SC41-24V (PFXGP2500SD)

Type STN Color LCD
Display Colors 64 colors (3-speed blink)
Backlight CCFL (Service life: 50,000 hrs. at 24hr. operation)
Resolution 640 × 480 pixels
Effective Display Area (mm) 211.2(W) × 158.4(H)
Brightness Control 4 levels of adjustment available via touch panel
Contrast Control 8 levels of adjustment available via touch panel
Language Character Sets ASCII: (Code page 850) Alphanumeric (incl. European characters)
Chinese: (GB2312-80 codes) simplified Chinese fonts
Japanese: ANK 158, Kanji : 6962 (JIS Standards 1 & 2)
Korean: (KSC5601 - 1992 codes) Hangul fonts
Taiwanese: (Big 5 codes) traditional Chinese fonts
Text 8 x 8 dots 80 char. × 60 rows
8 x 16 dots 80 char. × 30 rows
16 x 16 dots 40 char. × 30 rows
32 x 32 dots 20 char.× 15 rows
Character Sizes*1 8 × 8 dots, 8 × 16 dots, 16 × 16 dots, 32 × 32 dots
Font Sizes Width can be expanded 1 to 8 times.
Height can be expanded 1/2 *2, 1 to 8 times.
Application Memory FLASH EPROM 4MB
Data Backup Memory 256KB SRAM - uses lithium battery*3
Touch Panel Resolution 32 × 24 keys/ screen - 1 or 2 point touch
External
Interface
Serial Interface Asynchronous Transmission: RS232C/ RS422
Data Length: 7 or 8 bits
Stop Bit: 1 or 2 bits
Parity: None, Odd or Even
Data Transmission Speed: 2400 to 115.2kbps, 187.5Kbps*4
Expansion Serial
Interface
RS-232C
Asynchronous Transmission Method: RS232C,
Data Length: 7 or 8 bits,
Stop Bit: 1 or 2 bits,
Parity: None, Odd or Even,
Data Transmission Speed: 2400 to 38400 bps
Network Interface IEEE802.3, 10BASE-T
CF Card Interface 1 slot
External CF Card
Interface
CF Card Front Maintenance Unit Connector
Sound Output
Interface
External Speaker Connection (Terminal Block)
Monaural 1CH
Speaker Output 70mW (Rated Load: 8Ω, Frequency: 1kHz)
Sound Line Out Output 2.7Vp-p (Rated Load: 10kΩ)
Wire Gauge: AWG28 to AWG16
AUX
Input/Output
Interface
Remote
Reset
Input
Remote Reset Input: 1 point,
Input Voltage: DC24V ±10%,
Input Current: 4mA (TYP), Min. Input Pulse Width: 2ms
Operating Voltage: (When ON) Min. DC21.1V/ (When OFF) Max. DC3V
Isolation Method: Photocoupler Isolation
Output Output: 3 Points
(RUN Output: 1 point, System Alarm Output: 1 point, External Buzzer Output: 1 point)
Rated Voltage: DC24V,
Max. Rated Current: 50mA/ point,
Wire Gauge: AWG28 to AWG16
Printer Interface Compatible with NECPC-PR201/PL, EPSON ESC/P24-J84(C), HP Laser Jet, PCL 4 command, EPSON PM/Stylus (6-color ink), EPSON Stylus (4-color ink) compatible printers*5
Tool Connector Asynchronous TTL level nonprocedure command I/F

Used for transferring data between the GP application software and the GP.
Used for data transfer with the 2-Port feature.

Used for a variety of devices, including a bar-code reader.
  1. The display font will differ depending on which (language) character, or which size you select.
  2. Only available when using "1/2 Byte Character" settings via software. (Only Japanese, Chinese, Taiwanese and Korean characters.)
  3. A Lithium battery's lifetime is:
    10 years when the battery's ambient temperature is under 40℃
    4.1 years when the battery's ambient temperature is under 50℃
    1.5 years when the battery's ambient temperature is under 60℃
    When used for backup:
    Approximately 60 days, with a fully charged battery
    Approximately 6 days, with a half-charged battery
  4. SIEMENS SIMATIC S7-200/300/400 series (MPI port only). Please contact your Pro-face sales representative for supported models and other details.
  5. Printers with only Windows drivers cannot be used. However, certain types of printers with both Windows and DOS drivers can be used. For details, contact your local Pro-face distributor.
