Cảm biến DATALOGIC TL50-W-815

Power supply: 10 … 30 Vdc , reverse polarity protection
Ripple: 2 Vpp max.
Consumption: 50 mA max. at 24Vdc
Light emission: RGB LED (630nm red, 520nm green, 465nm blue)
Spot dimension: 1.5 x 5 mm at 9 mm
Operating distance: 9 mm
Depth of field: ± 3 mm (with standard 9 mm lens)
Setting: MARK push-button
BKGD push-button
Indicators: yellow OUTPUT LED
green READY LED
orange DELAY LED
Output type: 1 PNP output / 1 NPN output
Output current: 100 mA max.
Saturation voltage: ≤ 2 V
Response time: 33 µs
Switching frequency: 15 kHz
Operating mode: dark/light automatic
Timing function: 0 ... 20 ms selectable
Connections: 4-pole M12 connector
Electrical protection: class 2
Mechanical protection: IP67
Protection devices: A, B
Housing material: ABS
Lens material: PMMA
Weight: 90 g max.
Operating temperature: -10…55°C
Storage temperature: -20…70°C
Normativa di riferimento: EN 60947-5-2
